Dragon Resin 1kg

Dragon Resin – Durable Grey

High-precision resin developed for tabletop miniatures, figurines, and detailed models.
It delivers sharp detail, a smooth matt surface, and balanced mechanical properties, making it suitable for both display and practical use.

Designed for creators who require consistent results, dimensional accuracy, and a reliable printing workflow.

Best used for:

• Tabletop miniatures and gaming figures.

• Collectible figurines and character models.

• Scale models and terrain elements.

High Detail Reproduction
Captures fine textures, sharp edges, and intricate geometry with high dimensional accuracy.

Smooth Matt Surface
Neutral grey finish optimized for priming and painting directly after printing.

Balanced Mechanical Properties
Material combines strength and controlled flexibility, allowing for durable parts without excessive brittleness.

Low Shrinkage
Ensures reliable fit in multi-part models and maintains dimensional consistency.

Ease of Processing
Low viscosity enables smooth resin flow, accurate detail formation, and efficient cleaning.

Mechanical Properties (Post-Cured)

• Tensile Strength (yield): 45 MPa

• Tensile Strength (break): 36 MPa

• Tensile Modulus: 2090 MPa

• Elongation at break: 35%

• Shore Hardness: 83D

• Impact Strength (Izod): 41 J/m

Post-curing is required to achieve full mechanical performance.
Uncured prints do not represent final material properties and may show reduced strength.

Physical Properties

• Viscosity: 450 cPs @ 25°C

• Density: 1.11 g/cm³

• Heat Deflection Temperature: 52°C

• Water Absorption (24h): 0.91%

• Water Absorption (7 days): 2.07%

Compatibility

• Compatible with LCD / DLP printers

• Wavelength: 385–405 nm

Printing Parameters (Guidelines)

• Minimum wall thickness: 0.3 mm

• Minimum feature size: 0.4 mm

• Minimum hole diameter: 0.7 mm

• Recommended overhang: ≤ 45°

HIGH DETAIL PROFILES

(AA OFF, TURBO MODE)

Layer Height: 0.03 mm (30 µm)
Optimized for detail. More info under this table.

IMPORTANT

All settings are based on:

• Anti-Aliasing OFF

• Turbo / High-speed mode

• Well-calibrated machine

If Anti-Aliasing is enabled:
increase exposure by +10–20%

HOW TO USE

These are detail-oriented starting points:

• sharper edges

• less overexposure

• better surface definition

CALIBRATION NOTE

Final results depend on:

• LCD wear

• UV output variation

• FEP / nFEP condition

• temperature

• model geometry

adjust in steps of ±0.2 s

PRO TIP (important)

If:

• edges are soft → lower exposure

• supports fail → increase exposure slightly
